What a planner wants to see
Updated
A useful drawing shows the box projection, the colour, the guide width and the shutter both open and closed. A catalogue photo of a German house is not a drawing of your terrace.
What is being claimed
If you need an application, pay for the drawing rather than hoping the fitter's drawing is enough.
The illustration beside the claim
The worked opening for What a planner wants to see is 1.8 m wide by 2.35 m high, 4.23 square metres of glass. This figure puts 470 watts per square metre on the pane and uses a g-value of 0.7, about 1392 watts into the room if the curtain is up. An opaque external shutter, taken as stopping 85 percent of that gain while it is fully down, leaves about 209 watts and keeps about 1183 watts out. That is a noon figure for comparison. An internal blind does not get the same reduction. For What a planner wants to see, use the noon figure to compare two openings on the same house, then let a measured survey replace the figure.
An internal blind does not get that reduction, because the energy has already crossed the glass.
A night cover is not a consent
Winter figure for What a planner wants to see: glass at 1.4 W/m2K, 4.23 square metres, a 12 degree inside-outside gap and eight night hours. The bare pane is about 0.57 kWh a night on that crude sum. A closed shutter cutting about 24 percent of the flow leaves 0.43 kWh and saves about 0.14 kWh a night, only while it is down. Open it when you want winter sun.
Paper before manufacture
Stop What a planner wants to see if the only place for the box is a listed street front and nobody has written advice from the council. A photograph is not a manufacturing size.
Liverpool is only a setting for What a planner wants to see. The streets there are not the product.
How to use the figure
The 1.8 by 2.35 metre opening inside What a planner wants to see is there so a quote has something to disagree with. If the tape gives a different size, the tape wins.
The example drive is a wired motor, and the illustration is £2,732. A belt, a wired motor and a solar motor can share a curtain and still be different jobs. Compare those lines, not a single bold total.
What the survey still has to write down
For What a planner wants to see, ask where the box lands, what colour reference will be ordered, and how the curtain opens when the motor is dead. Those three answers move the job more than a rounded price.
Leave the lantern, the side light and the next elevation off the order unless they are drawn. What a planner wants to see covers one kind of opening. The house may have three.
When I would not order yet
What a planner wants to see should wait if the opening is an escape door with no way to raise a dead motor, or if the front is the elevation a conservation area was drawn to protect.
A photograph is not a manufacturing size. Two quotes for What a planner wants to see only compare when the slat, the box and the drive are the same kind of thing.
Questions worth asking the fitter
Is the price on this page a quote?
No. £2,732 illustrates What a planner wants to see for a 1.8 by 2.35 metre opening with a wired motor, at September 2026 rates. Your survey replaces it.
Does the shutter cover every pane?
It covers the opening it is built for. Here that example is 4.23 square metres. A roof lantern, a side light or the next elevation is another line.
What if planning is unclear?
Do not pay the factory for What a planner wants to see until a listed building, a conservation front, a flat or a shopfront has a written answer. Ordinary rear walls on houses are sometimes simpler.
What should two quotes share?
The same openings, the same slat type, and the same drive. What a planner wants to see uses a wired motor in the example so you can see how much the motor choice moves £2,732.
